32 CH. 4K UHD NETWORK VIDEO RECORDER
· H.265+ codec decoding
· Max. 256Mbps(32CH) input bandwidth
· Up to 8MP(4K) resolution for preview and playback
· Support to install up to 4 HDDs, up to 20TB per drive
· Full function network remote view via Internet (CMS, IE/Firefox/Chrome, Mac Safari)
· No limitation on adding devices to CMS, max. 128 channels preview (CMSONE)
· Support scan P2P QR code to connect NVR via Mobile app (AVY Mobile One)
· Support to save pictures/video to Dropbox storage (Dropbox)
· Support to save pictures/video to FTP server (built by user)
· 2 x HDMI/VGA Video output, Main HDMI support 4K resolution output up to 4K resolution
· Support HDD S.M.A.R.T. Monitoring
· NDAA compliant
| VIDEO | |
| IP Video Input | 32 Channels |
| Incoming Bandwidth (Mbps) | 256Mbps |
| Outgoing Bandwidth (Mbps) | 128Mbps |
| Video Compression | H.265+ / H.265 / H.264+ / H.264 |
| Audio Compression | G.711A; G.711U |
| Installation Wizard | Yes |
| Resolution | 8MP, 5MP, 3MP,2MP(1080P), 1.3MP(960P), 1.0MP(720P) |
| PLAYBACK | |
| Playback Frame Rate | 4K:60fps, 4MP:120fps, 2MP:240fps |
| Analytics | Face Detection, Human & Vehicle Detection, Intrusion detection, Tripwire Detection, Stationary Object Detection, Tripwire Count, Heat Map, Crowd Density Detection, Queue Length Detection, License Plate Detection, Rare Sound Detection, Loitering Detection, Region Entrance Detection, Region Exiting Detection |
| Supported Cameras for AI | Diversity Series Network Cameras |
| Event Triggers | MD(Sensitivity Level 1~8), Video Loss, Beep, Email, Push Notification to Mobile App |
| Playback Function | Fast forward / backward (2x, 4x, 8x,16x), Slow forward (1/2x, 1/4x, 1/8x,1/16x) |
| Playback | Max 16CH Playback |
| Fisheye | Support |
| INTERFACE | |
| Local UI |
UI5.0 |
| Web Monitoring | IE10/11, Safari V12.1 above, Firefox V.52 above, Chrome V.57 above, Edge V.79 above |
| Mobile Viewer | AVY Mobile One |
| Push Notification | Motion Event, AI, and Abnormal |
| Reset Button |
Factory Reset: Press 10 seconds |
| HDD Interface | SATA x 4, Max 20TB per HDD |
| VGA | 1（1024x768, 1280x720, 1280x1024, 1440x900, 1920x1080） |
| HDMI 1 | 1（1024x768, 1280x720, 1280x1024, 1440x900, 1920x1080, 3840x2160/EDID）/ Main Monitor supports up to 32CH Live View |
| HDMI 2 | 1（1024x768, 1280x720, 1280x1024, 1440x900, 1920x1080) Async output / SPOT Monitor supports up to 9CH Live View |
| SYSTEM | |
| PoE | No |
| Ethernet |
2 x Ethernet 10/100/1000 Base-T |
| USB | USB 2.0 x 2 (Front & Rear Panel), USB 3.0 x 1 (Rear Panel) |
| Audio Out | 1 |
| E-Sata |
1 |
| RS485 |
1 |
| Line-In |
1 |
| Alarm Input/out |
16 IN / 1 OUT |
| GENERAL | |
| OSD Language | English / French / Spanish / Portuguese / German / Italian / Greek / Danish / Finnish / Russian / Hebrew / Turkish / Bulgarian / Arabic / Korean / Japanese / Thai / Hindi / Romanian / Dutch / Polish |
| Power Consumption | 12W |
| Power Supply | DC12V |
| Working Environment | 14°F ~ 122°F-10°C~+50°C (14°F ~ 122°F) |
| Working Humidity | Less than 90%RH (Non-Condensing) |
| Dimensions | 14.88” × 12.83” × 2.60” (378mm x 326mm x 66mm) |
32 CH. 4K UHD NETWORK VIDEO RECORDER
